Product Description
Engineered with Komatsu's renowned SA6D125E-2 engine delivering 230 kW of rated power, this 2016 PC400-6 excavator represents proven hydraulic excellence in the 40-ton class. The variable piston pump system generates a maximum flow of 652 l/min at 38 Mpa, providing exceptional digging force of 257 kN at the bucket and 202 kN at the rod. This joint venture/import model combines robust construction with precise control for demanding excavation operations.
Performance specifications include:
- Operating weight: 41,400 kg with 1.8 m³ backhoe bucket capacity
- Maximum digging reach of 11,810 mm and depth capability to 7,760 mm
- Superior unloading height of 10,920 mm for efficient truck loading
- Rotation speed of 9.3 rpm with 3,500 mm rear turning radius
- Low ground pressure of 0.79 Kpa with 600 mm track plates
- Multiple travel speeds: 5.5/4.5/3.2 km/h for operational flexibility
Currently located in Guizhou, this PC400-6 maintains Komatsu's engineering standards for reliability and productivity in heavy construction and mining applications.
| Specifications | Value |
|---|---|
| No. | 1006690 |
| Tonnage (tons) | 40 |
| Working weight (kg) | 41400 |
| Bucket capacity (m³) | 1.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SA6D125E-2 |
| Rated power (kw/rpm) | 230 |
| Ground specific pressure (Kpa) | 0.79 |
| Rotation speed (rpm) | 9.3 |
| Bucket digging force (kN) | 257 |
| Rod digging force (kN) | 202 |
| Travel speed (km/h) | 5.5/4.5/3.2 |
| Main overflow set pressure (Mpa) | 38 |
| Maximum flow of main pump (l/min) | 652 |
| Main pump type | Variable piston pump |
| Total transport length (mm) | 11835 |
| Total transport width (mm) | 3430 |
| Total transport height (mm) | 3635 |
| Minimum ground clearance (mm) | 555 |
| Back end turning radius (mm) | 3500 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 11810 |
| Maximum digging depth (mm) | 7760 |
| Maximum unloading height (mm) | 10920 |
