Product Description
Built for high-output excavation and heavy-duty site work, this 2016 Komatsu PC460LC-8 delivers 46 tons of working weight and 257 kW of proven SAA6D125E-5 power. Equipped with a 2.1 m³ backhoe bucket, 7060mm boom, and 3380mm arm, this machine tackles deep foundation work with a maximum digging depth of 7790mm and a reach extending to 12005mm. Hydraulic muscle comes from dual variable piston pumps flowing 690 L/min at 37.8 MPa, generating 278 kN bucket digging force and 233 kN arm breakout force—ready for rock trenching, mass excavation, and demolition applications.
Currently located in Lishui, Zhejiang, this PC460LC-8 features water-cooled reliability, 650L fuel capacity for extended shifts, and robust undercarriage with dual sprockets and 600mm triple-grouser tracks. Travel speeds up to 5.5 km/h and a 70% grading ability ensure efficient repositioning across demanding terrain. Site-ready and inspection-welcome.
- 46-ton class with 2.1 m³ bucket capacity
- 12-meter maximum digging radius
- 690 L/min hydraulic flow for fast cycle times
- 11.04L displacement, 6-cylinder engine
- Available in Lishui, Zhejiang
| Specifications | Value |
|---|---|
| No. | 1018896 |
| Tonnage (tons) | 46 |
| Working weight (kg) | 46000 |
| Bucket capacity (m³) | 2.1 |
| Boom length (mm) | 7060 |
| Rod length (mm) | 3380 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | SAA6D125E-5 |
| Rated power (kw/rpm) | 257/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 125*150 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 11.04 |
| Ground specific pressure (Kpa) | 79.3 |
| Rotation speed (rpm) | 9.1 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 278 |
| Rod digging force (kN) | 233 |
| Maximum tractive force (kN) | 330 |
| Travel speed (km/h) | 5.5/4.2/3.0 |
| Maximum flow of main pump (l/min) | 690 |
| Traveling Hydraulic Circuit (Mpa) | 37.8 |
| Rotary Hydraulic Circuit (Mpa) | 27.9 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 37.8 |
| Pilot Oil Circuit (MPa) | 3.3 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-160*1270 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-185*1985 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-160*1570 |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 248 |
| Engine Oil changes (L) | 37 |
| Total transport length (mm) | 12040 |
| Total transport width (mm) | 3570 |
| Total transport height (mm) | 3660 |
| Counterweight ground clearance (mm) | 1320 |
| Minimum ground clearance (mm) | 567 |
| Minimum turning radius of front working device (mm) | 4805 |
| Back end turning radius (mm) | 3645 |
| Total track length (mm) | 5385 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3340 |
| Track ground length (mm) | 4350 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 12005 |
| Maximum digging depth (mm) | 7790 |
| Maximum excavation height (mm) | 10925 |
| Maximum unloading height (mm) | 7625 |
| Maximum vertical digging depth (mm) | 6600 |
| Maximum excavation radius of stop surface (mm) | 11800 |
