Product Description
Built on decades of engineering excellence, this 2013 Komatsu PC56-7 mini excavator delivers proven performance for contractors who demand reliability. Operating at 5.3 tons with a Komatsu S4D87E-1 engine producing 34.5kW, this compact machine combines precision hydraulics with robust construction. Maximum digging depth reaches 3,810mm while maintaining a compact transport footprint of just 5,935mm in length.
Komatsu's reputation in the used equipment market remains unmatched. Parts availability through extensive dealer networks ensures minimal downtime, while strong resale values protect your investment. This joint venture/import model features water-cooled operation, variable plunger travel motors, and a 26.5 MPa working hydraulic circuit designed for consistent performance across demanding applications.
- Working weight: 5,300kg with 0.055-0.22m³ bucket capacity
- Maximum digging radius: 6,130mm
- Fuel efficiency: 120L tank capacity
- Currently located in Luzhou, Sichuan Province
Backed by Komatsu's global service infrastructure, this PC56-7 represents a calculated investment in proven technology with long-term parts support and market-leading residual values.
| Specifications | Value |
|---|---|
| No. | 1008856 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5300 |
| Bucket capacity (m³) | 0.055-0.22 |
| Country of origin | Jining, Shandong Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu S4D87E-1 |
| Rated power (kw/rpm) | 34.5/2300 |
| Cooling mode | water-cooling |
| Displacement (L) | 2.434 |
| Working form | 4-stroke, water-cooled in-line, direct injection motor, stroke :102.4mm, cylinder diameter :87mm. |
| Ground specific pressure (Kpa) | 30.7 |
| Rotation speed (rpm) | 9 |
| Travel speed (km/h) | 2.6/4.1 |
| Rotary hydraulic motor type | Fixed plunger type x 1 |
| Type of walking hydraulic motor | Variable plunger type x 2 |
| Traveling Hydraulic Circuit (Mpa) | 26.5 |
| Rotary Hydraulic Circuit (Mpa) | 19.6 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 26.5 |
| Bucket cylinders - Number × diameter × stroke (mm) | 75 x 580 x 50 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 85 * 709.5 * 55 |
| Boom cylinders - Number × diameter × stroke (mm) | 90 * 689.5 * 55 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 55 |
| Engine Oil changes (L) | 9.7 |
| Coolant (L) | 8 |
| Total transport length (mm) | 5935 |
| Total transport width (mm) | 1960 |
| Total transport height (mm) | 2550 |
| Full cab height (mm) | 2550 |
| Minimum ground clearance (mm) | 320 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2500 |
| Track gauge (mm) | 1560 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 1960 |
| Track ground length (mm) | 1980 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3810 |
| Maximum excavation height (mm) | 5860 |
| Maximum unloading height (mm) | 4130 |
| Maximum vertical digging depth (mm) | 3060 |
| Bulldozer lift or depth (mm) | 355 |
| Maximum excavation radius of stop surface (mm) | 5980 |
