2014 Komatsu PC60-8

1/6
Buy Komatsu PC60-8 Used Excavator / 1
Buy Komatsu PC60-8 Used Excavator / 2
Buy Komatsu PC60-8 Used Excavator / 3
Buy Komatsu PC60-8 Used Excavator / 4
Buy Komatsu PC60-8 Used Excavator / 5
Buy Komatsu PC60-8 Used Excavator / 6

Product Description

Expand your operational capacity with this 2014 Komatsu PC60-8 mini excavator, purpose-built for contractors requiring dependable fleet reinforcement. Powered by a Komatsu SAA4D95LE-5 turbocharged engine delivering 40.7 kW at 1950 rpm, this 6-ton machine provides consistent performance across residential, utility, and light commercial projects. The water-cooled 4-cylinder engine ensures reliable operation even during extended shifts.

  • Working weight: 6,180 kg with 0.25–0.37 m³ bucket capacity
  • Impressive digging reach: 6,190 mm maximum radius, 3,900 mm depth
  • Hydraulic muscle: 54.8 kN bucket digging force, 39.8 kN arm force
  • Variable piston pump system with 172 l/min flow rate
  • Compact transport dimensions: 6,035 mm (L) × 2,225 mm (W) × 2,620 mm (H)
  • Currently located in Jiangxi, China—ready for immediate deployment

Minimize downtime and maintain project momentum by integrating this proven Komatsu unit into your existing equipment roster. Contact Fair Trade Machinery today for competitive pricing and international shipping solutions.

SpecificationsValue
No.1038897
Tonnage (tons)6
Working weight (kg)6180
Bucket capacity (m³)0.25~0.37
Country of originJining, Shandong Province
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeKomatsu SAA4D95LE-5
Rated power (kw/rpm)40.7/1950
Cooling modewater-cooling
Cylinder diameter × stroke (mm)95*115
Number of cylinders (PCS)4
Displacement (L)3.26
Working formturbocharging
Ground specific pressure (Kpa)28.4
Rotation speed (rpm)10
Bucket digging force (kN)54.8
Rod digging force (kN)39.8
Maximum tractive force (kN)56.6
Travel speed (km/h)2.8-4.5
Maximum flow of main pump (l/min)172
Traveling Hydraulic Circuit (Mpa)24.5
Rotary Hydraulic Circuit (Mpa)21.1
Hydraulic crushing pipeline is standardno
Main pump typeVariable piston pump
Working Hydraulic Circuit (Mpa)24.5
Pilot Oil Circuit (MPa)2.9
Bucket cylinders - Number × diameter × stroke (mm)1-90*710
Bucket rod cylinders - Number × diameter × stroke (mm)1-100*865
Boom cylinders - Number × diameter × stroke (mm)1-115*840
Fuel Tank (L)130
Hydraulic Tank (L)95
Engine Oil changes (L)12.5
Coolant (L)10
Total transport length (mm)6035
Total transport width (mm)2225
Total transport height (mm)2620
Counterweight ground clearance (mm)750
Minimum ground clearance (mm)350
Minimum turning radius of front working device (mm)1700
Back end turning radius (mm)1750
Total track length (mm)2765
Track gauge (mm)1700
Track plate width (mm)450
Total track width (mm)2150
Track ground length (mm)2130
Number of sprockets (single side) (each)1
Number of wheels (single side) (each)5
Number of track plates (single side) (PCS)38
Maximum digging radius (mm)6190
Maximum digging depth (mm)3900
Maximum excavation height (mm)7030
Maximum unloading height (mm)4925
Maximum vertical digging depth (mm)3350
Maximum excavation radius of stop surface (mm)6045
see more

Overview

No.1038897

Brand Name:

Komatsu

Model Number:

PC60-8

Year:

2014

Location:

Jiangxi China
