Product Description
Built for demanding jobsites, this 2018 Lonking LG850 wheel loader delivers proven performance with operator-centered engineering. Powered by a 162kW water-cooled engine displacing 9.726L, this 15,850kg machine handles a 5,000kg rated load with authority. The 3m³ bucket generates 165kN of digging force, moving material efficiently across construction and mining applications.
Operators benefit from excellent sightlines and responsive handling throughout the work cycle. The compact 6,870mm turning radius enables precise positioning in confined spaces, while the dual-speed transmission (11.5/36 km/h) balances maneuverability with productive travel speeds. Hydraulic performance remains consistent at 16 bars rated pressure, completing lift cycles in 6.5 seconds and full ternary sequences in 12.5 seconds.
- 162kW @ 2,200 RPM water-cooled diesel engine
- 5,000kg rated load capacity with 3m³ bucket
- 165kN digging force for challenging materials
- 6,870mm outer turning radius for tight maneuvering
- Currently located in Yichun, Jiangxi Province
| Specifications | Value |
|---|---|
| No. | 1038277 |
| Engine type | |
| Rated power (kw/rpm) | 162/2200 |
| Cooling mode | water-cooling |
| Working form | |
| Exhaust volume (L) | 9.726 |
| Bucket capacity (m³) | 3 |
| Rated load (tons) | |
| Rated load (kg) | 5000 |
| Digging force (lifting force) (kN) | 165 |
| Machine operating weight (kg) | 15850 |
| Drive axle model | |
| Minimum turning radius of outer wheel center line | 5694 |
| Turning radius - Outside of bucket (mm) | 6870 |
| Rated working pressure (bars) | 16 |
| Lift (s) | 6.5 |
| Ternary sum (s) | 12.5 |
| Gearbox brand and model | |
| Speed 1 gear (km/h) | 11.5 |
| Speed 2 (km/h) | 36 |
| Machine length (mm) | 7430 |
| Machine width (mm) | 3000 |
| Machine height (mm) | 3310 |
