2020 Sany SY125C

1/5
Buy Sany SY125C Used Excavator / 1
Buy Sany SY125C Used Excavator / 2
Buy Sany SY125C Used Excavator / 3
Buy Sany SY125C Used Excavator / 4
Buy Sany SY125C Used Excavator / 5

Product Description

Well-maintained 2020 Sany SY125C excavator available in Sichuan, China. This 12.5-ton class machine offers reliable performance for mid-sized construction and earthmoving operations. The SY125C is known for its fuel efficiency, stable hydraulic system, and comfortable operator cab, making it suitable for extended shifts in demanding conditions.

Key features include:

  • Proven Sany engineering with robust build quality
  • Versatile 12-ton operating weight class
  • Efficient hydraulic system for productive digging cycles
  • Low operating hours for a 2020 model year
  • Currently located in Sichuan Province for inspection

This unit has been maintained in good working condition and is ready for immediate deployment. Suitable for contractors and fleet operators seeking dependable equipment at competitive pricing. Contact us for detailed specifications, service records, and shipping arrangements.

SpecificationsValue
No.1137599
Tonnage (tons)12
Working weight (kg)12450
Bucket capacity (m³)0.22-0.7 (0.55)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeIsuzu 4JJ1-XDJAG-01-C3
Rated power (kw/rpm)73/2000
Cooling modewater-cooling
Maximum torque (N.m)365/1600
Displacement (L)2.999
Ground specific pressure (Kpa)41.6
Rotation speed (rpm)13.06
Climbing ability (%)70
Bucket digging force (kN)90.6
Rod digging force (kN)57.2
Travel speed (km/h)5.5/3.5
Fuel Tank (L)240
Hydraulic Tank (L)150
Engine Oil changes (L)15
Total transport length (mm)7280
Total transport width (mm)2550
Total transport height (mm)2890
Full cab height (mm)2740
Minimum ground clearance (mm)425
Minimum turning radius of front working device (mm)2880
Back end turning radius (mm)2205
Onboard width (mm)2490
Total track length (mm)3360
Track gauge (mm)1990
Track plate width (mm)500
Track ground length (mm)2680
Maximum height at minimum turning radius (mm)5905
Number of sprockets (single side) (each)1
Number of wheels (single side) (each)6
Number of track plates (single side) (PCS)41
Maximum digging radius (mm)7735
Maximum digging depth (mm)5190
Maximum excavation height (mm)7695
Maximum unloading height (mm)5440
Maximum vertical digging depth (mm)4720
see more

Overview

No.1137599

Brand Name:

Sany

Model Number:

SY125C

Year:

2020

Location:

Sichuan China

Pub Date
