Product Description
This 2020 Sany SY125C midi excavator offers reliable performance for contractors and operators seeking value in the used equipment market. Manufactured by Sany Heavy Industry, a leading Chinese construction machinery producer, this 12.5-ton class excavator is well-suited for utility work, residential construction, and light demolition applications.
Currently located in Guangdong, China, this machine is being offered at a competitive price point. The seller notes that attachment compatibility includes grapple and clamp options, expanding operational versatility beyond standard bucket work.
- Model Year: 2020
- Weight Class: 12.5 tons
- Location: Guangdong Province, China
- Attachment-ready for grapples and hydraulic clamps
Prospective buyers should arrange independent inspection to verify machine condition, operating hours, and maintenance history. Shipping and export documentation can be coordinated from the Guangdong location to international destinations.
| Specifications | Value |
|---|---|
| No. | 1161914 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12450 |
| Bucket capacity (m³) | 0.22-0.7 (0.55) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu 4JJ1-XDJAG-01-C3 |
| Rated power (kw/rpm) | 73/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 365/1600 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 41.6 |
| Rotation speed (rpm) | 13.06 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 90.6 |
| Rod digging force (kN) | 57.2 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 15 |
| Total transport length (mm) | 7280 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 2890 |
| Full cab height (mm) | 2740 |
| Minimum ground clearance (mm) | 425 |
| Minimum turning radius of front working device (mm) | 2880 |
| Back end turning radius (mm) | 2205 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3360 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2680 |
| Maximum height at minimum turning radius (mm) | 5905 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 6 |
| Number of track plates (single side) (PCS) | 41 |
| Maximum digging radius (mm) | 7735 |
| Maximum digging depth (mm) | 5190 |
| Maximum excavation height (mm) | 7695 |
| Maximum unloading height (mm) | 5440 |
| Maximum vertical digging depth (mm) | 4720 |
