Product Description
This 2020 Sany SY125C excavator represents a reliable mid-size solution for construction and earthmoving operations. With approximately four years of operational history, this 12.5-ton class machine delivers proven performance in demanding work environments. The SY125C is known for its fuel efficiency and hydraulic system responsiveness, making it suitable for various applications including trenching, loading, and site preparation.
Currently located in Sichuan, China, this unit offers convenient viewing arrangements for serious buyers. The machine has been maintained in operational condition and is ready for immediate deployment.
- Year of Manufacture: 2020
- Operating Weight Class: 12.5 tons
- Brand: Sany
- Model: SY125C
- Location: Sichuan Province, China
- Viewing: Available by appointment
Ideal for contractors seeking dependable performance in a proven excavator platform. Contact us for detailed specifications and viewing arrangements.
| Specifications | Value |
|---|---|
| No. | 1164355 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12450 |
| Bucket capacity (m³) | 0.22-0.7 (0.55) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu 4JJ1-XDJAG-01-C3 |
| Rated power (kw/rpm) | 73/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 365/1600 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 41.6 |
| Rotation speed (rpm) | 13.06 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 90.6 |
| Rod digging force (kN) | 57.2 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 240 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 15 |
| Total transport length (mm) | 7280 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 2890 |
| Full cab height (mm) | 2740 |
| Minimum ground clearance (mm) | 425 |
| Minimum turning radius of front working device (mm) | 2880 |
| Back end turning radius (mm) | 2205 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3360 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2680 |
| Maximum height at minimum turning radius (mm) | 5905 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 6 |
| Number of track plates (single side) (PCS) | 41 |
| Maximum digging radius (mm) | 7735 |
| Maximum digging depth (mm) | 5190 |
| Maximum excavation height (mm) | 7695 |
| Maximum unloading height (mm) | 5440 |
| Maximum vertical digging depth (mm) | 4720 |
