2021 Sany SY125C

1/5
Buy Sany SY125C Used Excavator / 1
Buy Sany SY125C Used Excavator / 2
Buy Sany SY125C Used Excavator / 3
Buy Sany SY125C Used Excavator / 4
Buy Sany SY125C Used Excavator / 5

Product Description

This 2021 Sany SY125C hydraulic excavator offers reliable performance for mid-range earthmoving operations. Located in Sichuan, China, this unit represents Sany's proven 12-ton class design with approximately three years of operational history. The SY125C is engineered for general construction, landscaping, and utility work where maneuverability and reach are essential.

Key features of this model include:

  • 12.5-ton operating weight suitable for diverse job sites
  • Fuel-efficient engine meeting current emissions standards
  • Hydraulic system designed for productive cycle times
  • Robust undercarriage for extended service life
  • Spacious operator cab with standard controls

As a used unit from 2021, this excavator provides an economical entry point for contractors seeking established Sany quality without new equipment costs. Inspection recommended prior to purchase.

SpecificationsValue
No.1145539
Tonnage (tons)12
Working weight (kg)12450
Bucket capacity (m³)0.22-0.7 (0.55)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeIsuzu 4JJ1-XDJAG-01-C3
Rated power (kw/rpm)73/2000
Cooling modewater-cooling
Maximum torque (N.m)365/1600
Displacement (L)2.999
Ground specific pressure (Kpa)41.6
Rotation speed (rpm)13.06
Climbing ability (%)70
Bucket digging force (kN)90.6
Rod digging force (kN)57.2
Travel speed (km/h)5.5/3.5
Fuel Tank (L)240
Hydraulic Tank (L)150
Engine Oil changes (L)15
Total transport length (mm)7280
Total transport width (mm)2550
Total transport height (mm)2890
Full cab height (mm)2740
Minimum ground clearance (mm)425
Minimum turning radius of front working device (mm)2880
Back end turning radius (mm)2205
Onboard width (mm)2490
Total track length (mm)3360
Track gauge (mm)1990
Track plate width (mm)500
Track ground length (mm)2680
Maximum height at minimum turning radius (mm)5905
Number of sprockets (single side) (each)1
Number of wheels (single side) (each)6
Number of track plates (single side) (PCS)41
Maximum digging radius (mm)7735
Maximum digging depth (mm)5190
Maximum excavation height (mm)7695
Maximum unloading height (mm)5440
Maximum vertical digging depth (mm)4720
see more

Overview

No.1145539

Brand Name:

Sany

Model Number:

SY125C

Year:

2021

Location:

Sichuan China

Pub Date
