Product Description
Offered for sale: a 2023 Sany SY16C mini excavator, acquired new in 2023 and currently located in Kunming, Yunnan Province, China. This is a compact 1.6-ton-class unit suited to utility trenching, landscaping and tight urban job sites. The seller reports the machine as running without faults and invites buyers to bring their own technician for a full on-site inspection before any commitment is made.
- Model: Sany SY16C, purchased 2023
- Location: Kunming, Yunnan — yard viewing by appointment
- Condition: seller states performance is trouble-free; inspection encouraged, not restricted
- Typical applications: trenching, drainage, garden and municipal works
- Documentation: machine papers available for review during inspection
Hour meter reading, undercarriage condition and serial details can be supplied on request. Any specification of interest should be verified directly against the machine and its own documentation at the viewing, rather than taken from listings. Inland transport and export arrangements from Yunnan can be handled through the buyer's appointed agent. B2B enquiries welcome.
| Specifications | Value |
|---|---|
| No. | 1157576 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1850 |
| Bucket capacity (m³) | 0.02-0.06(0.04) |
| Country of origin | China |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV70 |
| Rated power (kw/rpm) | 10.3/2200 |
| Maximum torque (N.m) | 48.5~52.4 |
| Displacement (L) | 0.854 |
| Ground specific pressure (Kpa) | 29.1 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 58 |
| Bucket digging force (kN) | 15.2 |
| Rod digging force (kN) | 9.2 |
| Maximum tractive force (kN) | 15.5 |
| Travel speed (km/h) | 2.1~3.7 |
| Fuel Tank (L) | 23 |
| Hydraulic Tank (L) | 21 |
| Engine Oil changes (L) | 2 |
| Coolant (L) | 4.5 |
| Total transport length (mm) | 3575 |
| Total transport width (mm) | 980/1350 |
| Total transport height (mm) | 2420 |
| Counterweight ground clearance (mm) | 470 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1655 |
| Back end turning radius (mm) | 920 |
| Onboard width (mm) | 980 |
| Total track length (mm) | 1585 |
| Track gauge (mm) | 750/1220 |
| Track plate width (mm) | 230 |
| Total track width (mm) | 3575 |
| Track ground length (mm) | 1225 |
| Maximum height at minimum turning radius (mm) | 2745 |
| Number of wheels (single side) (each) | 3 |
| Maximum digging radius (mm) | 4000 |
| Maximum digging depth (mm) | 2360 |
| Maximum excavation height (mm) | 3665 |
| Maximum unloading height (mm) | 2635 |
| Maximum vertical digging depth (mm) | 2215 |
| Bulldozer lift or depth (mm) | 310/320 |
| Dodging plate width × height (mm) | 3575 x 270 |
| Maximum excavation radius of stop surface (mm) | 3900 |
