Product Description
This 2013 Sany SY195C excavator represents reliable performance from one of China's leading heavy equipment manufacturers. With an operating weight of approximately 19.5 tons, this mid-size crawler excavator is well-suited for construction, earthmoving, and infrastructure projects requiring versatile digging capabilities.
Currently located in Hunan, China, this machine offers the robust build quality Sany is known for in the Asian market. The SY195C features a hydraulic system designed for efficient fuel consumption and responsive control, making it suitable for contractors seeking dependable used equipment at competitive pricing.
- Year of Manufacture: 2013
- Model: Sany SY195C
- Machine Type: Hydraulic Crawler Excavator
- Approximate Operating Weight: 19.5 tons
- Current Location: Hunan Province, China
Ideal for buyers seeking established Chinese machinery with proven track records in demanding applications. Contact us for current condition assessment, shipping quotes, and availability.
| Specifications | Value |
|---|---|
| No. | 1143945 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
