Product Description
With a robust 19-ton working weight and a powerful 4M50 engine, this 2018 Sany SY195C excavator is equipped to handle a variety of demanding tasks. Featuring a bucket capacity of 0.8 to 1.1 m³, it excels in digging, grading, and demolition. The machine delivers a rated power of 118 kW at 2000 rpm, ensuring efficient performance. Its maximum torque of 580 N.m at 1600 rpm and a climbing ability of 70% (35°) make it suitable for challenging terrains. Equipped with a backhoe bucket, this excavator provides a strong bucket digging force of 138 kN and a rod digging force of 103 kN, making it ideal for tough excavation jobs. With a travel speed of 5.4/3.3 km/h and a fuel tank capacity of 340 L, it ensures long operational hours without frequent refueling. Located in 浙江省丽水市, this Sany SY195C is ready to work immediately, providing the reliability and performance needed for your site.
| Specifications | Value |
|---|---|
| No. | 1001040 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
