Product Description
This 2018 Sany SY195C crawler excavator represents a solid mid-size solution for construction and earthmoving operations. Manufactured by one of China's leading heavy equipment producers, this model delivers reliable performance in a proven 19-ton class platform. Currently located in Sichuan, China, this machine offers an accessible entry point into quality used excavation equipment.
The SY195C is engineered for versatility across multiple applications including site preparation, trenching, and material handling. Key features include:
- Robust hydraulic system for consistent digging performance
- Spacious operator cabin with ergonomic controls
- Durable undercarriage designed for extended service life
- Fuel-efficient engine meeting operational cost requirements
- Straightforward maintenance access points
With approximately six years of service, this unit provides an economical option for contractors seeking dependable excavation capacity without the premium of new equipment. Ideal for regional infrastructure projects, mining support operations, or general contracting work.
| Specifications | Value |
|---|---|
| No. | 1088384 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
