Product Description
This 2018 Sany SY195C crawler excavator offers reliable performance for medium-duty construction and earthmoving applications. Manufactured by Sany Heavy Industry, a leading Chinese construction equipment producer, this 19-ton class machine combines proven hydraulic technology with efficient fuel consumption. The SY195C features a robust undercarriage designed for stability on varied terrain, making it suitable for excavation, trenching, and material handling tasks.
Currently located in Zhejiang Province, China, this unit represents an economical entry point into quality used excavation equipment. Key features include:
- Operating weight approximately 19,500 kg
- Tier 2/Stage II compliant diesel engine
- Standard boom and arm configuration
- Enclosed operator cabin with climate control
- Hydraulic quick coupler compatibility
Ideal for contractors seeking dependable mid-size excavation capacity at competitive pricing. Inspection welcome by appointment.
| Specifications | Value |
|---|---|
| No. | 1171132 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
