Product Description
This 2019 Sany SY195C excavator offers reliable performance at a competitive price point. Currently located in Chongqing, China, this mid-size crawler excavator from one of China's leading construction equipment manufacturers represents excellent value for contractors and earthmoving operations.
The SY195C is known for its robust hydraulic system and fuel efficiency in the 19-ton class. With approximately six years of operational history, this unit has been maintained in good working condition and demonstrates solid performance characteristics across standard excavation applications.
- Year of Manufacture: 2019
- Make: Sany
- Model: SY195C
- Location: Chongqing, China
- Condition: Good operational performance
- Pricing: Competitively priced for immediate sale
Ideal for construction sites, infrastructure projects, and general earthmoving work. Inspection and detailed specifications available upon serious inquiry.
| Specifications | Value |
|---|---|
| No. | 1081844 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
