Product Description
This 2019 Sany SY195C excavator offers reliable performance for mid-size excavation projects. Located in Hunan, China, this machine comes equipped with factory-original track chains and a fully functional air conditioning system, ensuring operator comfort during extended work shifts.
With over 110,000 operating hours recorded, this unit has proven its durability in demanding conditions. The excavator is sold without a hydraulic hammer attachment, making it ideal for operators who prefer to configure their own auxiliary equipment based on specific job requirements.
Key features include:
- Original equipment manufacturer (OEM) track chains
- Operational air conditioning system
- Well-maintained 19-ton class excavator
- Suitable for earthmoving, trenching, and general construction applications
This Sany SY195C represents a practical choice for contractors seeking proven Chinese manufacturing quality at competitive pricing.
| Specifications | Value |
|---|---|
| No. | 1173116 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
