Product Description
This 2012 Sany SY195C-9 excavator is available in Jiangxi, China, offering reliable performance for demanding construction and earthmoving applications. The machine comes equipped with a hydraulic breaker attachment, providing added versatility for demolition and rock-breaking tasks. As a first-hand local source, this excavator has been well-documented with detailed photos and operational videos available for review.
- Year of Manufacture: 2012
- Model: Sany SY195C-9
- Operating Weight Class: Approximately 19 tons
- Included: Hydraulic hammer attachment
- Location: Jiangxi Province, China
- Condition: Used, test operation available upon request
The Sany SY195C-9 is a mid-size crawler excavator known for its robust build quality and operational efficiency. Prospective buyers are welcome to schedule an on-site inspection and test drive to evaluate the machine's current condition and performance capabilities. Complete documentation and video footage demonstrate the excavator's functionality and maintenance history.
| Specifications | Value |
|---|---|
| No. | 1173900 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20700 |
| Bucket capacity (m³) | 0.83 (optional 0.7~1.0) |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | SANY D06S2 |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6-cylinder |
| Working form | Six-cylinder four-stroke turbocharged direct injection engine |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 135 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9560 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2955 |
| Full cab height (mm) | 2990 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3755 |
| Back end turning radius (mm) | 2890 |
| Onboard width (mm) | 2710 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 (800/700 optional) |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging radius (mm) | 9740 |
| Maximum digging depth (mm) | 6410 |
| Maximum excavation height (mm) | 9410 |
| Maximum unloading height (mm) | 6490 |
| Maximum vertical digging depth (mm) | 5790 |
