Product Description
Featuring advanced electric drive technology, the Sany SY19E电动 offers unparalleled efficiency and performance. With its robust design, this excavator ensures smooth handling and exceptional stability, even on challenging terrains. Operators will appreciate the spacious cabin, which provides excellent visibility to all working areas, enhancing safety and precision during operations.
- Electric drive for high efficiency and low operational costs
- Enhanced stability and control for precise maneuvering
- Superior cabin visibility for safer operation
- Ideal for a variety of construction and excavation tasks
| Specifications | Value |
|---|---|
| No. | 1056796 |
| Tonnage (tons) | 1 |
| power | power-driven |
| manufacturer | Made in China |
| bucket | backhoe |
| Total transport length (mm) | 3624 |
| Total transport width (mm) | 980/1350 |
| Total transport height (mm) | 2440 |
| Minimum turning radius of front working device (mm) | 1655 |
| Back end turning radius (mm) | 920 |
| Total track length (mm) | 1585 |
| Track gauge (mm) | 750/1120 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1225 |
| Maximum digging radius (mm) | 4000 |
| Maximum digging depth (mm) | 2360 |
| Maximum excavation height (mm) | 3665 |
| Maximum unloading height (mm) | 2635 |
| Maximum vertical digging depth (mm) | 2215 |
| Bulldozer lift or depth (mm) | 310/320 |
| Maximum excavation radius of stop surface (mm) | 3900 |
