Product Description
Engineered for precision and all-day productivity, this 2016 Sany SY205C delivers exceptional operator comfort and control across demanding excavation tasks. Powered by a robust 118 kW engine, this 20-ton hydraulic excavator combines proven mechanical reliability with intelligent cabin design, ensuring reduced fatigue during extended shifts. Operators benefit from panoramic visibility and intuitive controls that enhance accuracy when navigating tight jobsites or executing complex digging sequences.
- Operator-Centric Design: Spacious cab with 3075 mm height provides superior sightlines to bucket, tracks, and surrounding terrain
- Stable Performance: 47.3 kPa ground pressure and 2380 mm track gauge deliver balanced weight distribution on soft or uneven ground
- Responsive Handling: 11 rpm swing speed and 2900 mm rear turning radius enable smooth positioning in confined areas
- Proven Capacity: 1.0 m³ bucket with 138 kN digging force handles varied materials efficiently
- Reliable Mobility: Dual travel speeds (5.4/3.3 km/h) and 70% gradeability tackle challenging terrain confidently
Curr
| Specifications | Value |
|---|---|
| No. | 1021829 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
