Product Description
This 2019 Sany SY205C excavator represents a reliable mid-range solution for contractors seeking proven performance in demanding applications. Manufactured by one of China's leading heavy equipment producers, this 20-ton class machine combines operational efficiency with robust construction suitable for earthmoving, grading, and general excavation work.
Currently located in Sichuan, China, this unit offers excellent value in the used equipment market. The SY205C is known for its fuel-efficient engine, responsive hydraulics, and operator-friendly cab design. With approximately five years of service, this excavator provides a cost-effective alternative to new equipment while maintaining the durability and support network Sany is recognized for globally.
- Year: 2019
- Model: Sany SY205C
- Class: 20-ton excavator
- Location: Sichuan, China
- Condition: Used
Ideal for construction firms, mining operations, and infrastructure projects requiring dependable excavation capability.
| Specifications | Value |
|---|---|
| No. | 1168275 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
