2022 Sany SY205C

1/7
Buy Sany SY205C Used Excavator / 1
Buy Sany SY205C Used Excavator / 2
Buy Sany SY205C Used Excavator / 3
Buy Sany SY205C Used Excavator / 4
Buy Sany SY205C Used Excavator / 5
Buy Sany SY205C Used Excavator / 6
Buy Sany SY205C Used Excavator / 7

Product Description

This 2022 Sany SY205C is a mid-size crawler excavator configured for earthmoving work. It is offered out of Shandong, China — one of the country's largest concentrations of used construction equipment, with established road and port links for export shipping.

The SY205C sits in the 20-ton class and is a common choice for general excavation, civil works and site preparation. Machines in this configuration typically feature:

  • Approximately 20-ton class operating weight
  • Standard boom and arm with a general-purpose digging bucket
  • Crawler undercarriage with steel tracks
  • Enclosed operator cab with air conditioning
  • Diesel engine matched to the 20-ton class

This unit has seen working service and is presented as a used machine, not as new stock. Hour meter reading, maintenance records, undercarriage condition and a full inspection report can be supplied on request, and the machine is available for physical inspection or third-party survey in Shandong before purchase.

Contact us for current availability, pricing and additional photographs.

SpecificationsValue
No.1156899
Tonnage (tons)20
Working weight (kg)21500
Bucket capacity (m³)0.9~1.1(1.0)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Rated power (kw/rpm)118/2000
Ground specific pressure (Kpa)47.3
Rotation speed (rpm)11
Climbing ability (%)70% / 35 °
Bucket digging force (kN)138
Rod digging force (kN)109
Travel speed (km/h)5.4/3.3
Total transport length (mm)9680
Total transport width (mm)2980
Total transport height (mm)3440
Full cab height (mm)3075
Minimum ground clearance (mm)440
Minimum turning radius of front working device (mm)3730
Back end turning radius (mm)2900
Onboard width (mm)2875
Total track length (mm)4160
Track gauge (mm)2380
Track plate width (mm)600
Track ground length (mm)3360
Maximum height at minimum turning radius (mm)7680
Maximum digging radius (mm)10280
Maximum digging depth (mm)6600
Maximum excavation height (mm)9600
Maximum unloading height (mm)6730
see more

Overview

No.1156899

Brand Name:

Sany

Model Number:

SY205C

Year:

2022

Location:

Shandong China

Pub Date:

Are you interested in this machine?

Please contact us
