Product Description
This 2022 Sany SY205C excavator offers proven performance for earthmoving and construction applications. As part of Sany's established 20-ton class lineup, the SY205C delivers reliable hydraulic power and operational efficiency suited to mid-sized jobsites. The machine is currently located in Hubei, China, and represents a recent model year with minimal operational history.
- Year of Manufacture: 2022
- Model: Sany SY205C
- Weight Class: Approximately 20 tons
- Location: Hubei Province, China
- Condition: Used equipment with low hours
Sany excavators are recognized for robust build quality and comprehensive dealer support networks across Asia and emerging markets. This unit is available for inspection and export arrangements. Contact us for technical specifications, current machine hours, and shipping solutions tailored to your operational requirements.
| Specifications | Value |
|---|---|
| No. | 1173073 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
