Product Description
This 2023 Sany SY205C excavator represents a solid opportunity for contractors seeking reliable hydraulic excavation equipment. Located in Sichuan, China, this medium-class crawler excavator comes from Sany's proven 200-series lineup, known for dependable performance in earthmoving, trenching, and site preparation applications.
The SY205C offers the balance of reach, digging force, and fuel efficiency expected from modern hydraulic excavators in its weight class. With minimal operating hours since its 2023 manufacture, this machine shows limited wear and remains well-suited for construction, infrastructure, and demolition projects.
- Year of Manufacture: 2023
- Model: Sany SY205C
- Location: Sichuan Province, China
- Condition: Used, low hours
- Available as part of equipment package deal
Inspection and shipping arrangements can be coordinated through our Sichuan facility. Contact us for detailed specifications, service records, and current availability.
| Specifications | Value |
|---|---|
| No. | 1162860 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
