Product Description
Discover the reliability and efficiency of the 2024 Sany SY205C, a robust excavator designed for demanding industrial applications. Located in Guangdong, China, this used machine has accumulated 1300 operational hours, showcasing its durability and performance in various construction environments. The SY205C is known for its powerful digging force, excellent stability, and fuel efficiency, making it a preferred choice for medium to large-scale projects. This model is equipped with advanced hydraulic systems and ergonomic controls, ensuring smooth operation and reduced operator fatigue.
- Year: 2024
- Brand: Sany
- Model: SY205C
- Location: Guangdong, China
- Operational Hours: 1300
| Specifications | Value |
|---|---|
| No. | 1123786 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
