Product Description
Built for operator efficiency and precision, this 2016 Sany SY215C excavator combines proven reliability with practical performance on demanding jobsites. Powered by a Mitsubishi 4M50 engine delivering 118 kW at 2000 rpm, this 21-ton machine provides consistent hydraulic power for extended operational cycles. The water-cooled four-cylinder engine generates 580 N.m of maximum torque, ensuring responsive control during heavy digging and loading tasks.
Operators benefit from excellent visibility and stable handling characteristics inherent to this generation of Sany excavators. With a 440 mm ground clearance and 47.4 kPa ground pressure, the SY215C maintains stability across varied terrain while minimizing surface damage. The 1.1 m³ backhoe bucket delivers 138 kN digging force and reaches a maximum depth of 6,600 mm, supported by a 10,280 mm working radius for versatile positioning.
- Working weight: 21,900 kg with robust undercarriage design
- Travel speeds: 5.4/3.3 km/h for efficient repositioning
- Fuel capacity: 390 L for extended runtime
- Currently located in Changzhou, Jiangsu, China
| Specifications | Value |
|---|---|
| No. | 1023016 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
