Product Description
This 2017 Sany SY215C excavator offers reliable performance for demanding construction and earthmoving applications. Manufactured by one of China's leading heavy equipment producers, this 21-ton class machine features a robust hydraulic system and proven durability in challenging job sites. Currently located in Sichuan, China, this unit represents excellent value in the mid-size excavator segment.
Key features include:
- 2017 model year with documented service history
- Sany SY215C configuration with enhanced specifications
- Suitable for excavation, trenching, and material handling
- Operating weight approximately 21,500 kg
- Diesel-powered engine for fuel efficiency
- Available for inspection in Sichuan, China
This excavator has been maintained according to manufacturer guidelines and is ready for immediate deployment. Ideal for contractors seeking dependable equipment at competitive pricing in the Asian market.
| Specifications | Value |
|---|---|
| No. | 1171453 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
