Product Description
This 2020 Sany SY215C excavator represents reliable mid-size performance from one of China's leading heavy equipment manufacturers. Currently located in Jiangsu, China, this machine offers proven capabilities for construction, earthmoving, and general excavation applications. The SY215C is known for its robust hydraulic system, fuel efficiency, and operator comfort in demanding job site conditions.
Key specifications include:
- Year of Manufacture: 2020
- Brand: Sany
- Model: SY215C
- Location: Jiangsu Province, China
- Machine Category: Medium excavator
- Suitable for earthmoving, trenching, and construction projects
This unit is available for immediate inspection and export coordination. Delivery timeframes and logistics support can be arranged to your destination port. Contact us for detailed technical specifications, current condition reports, and competitive pricing for this Sany excavator.
| Specifications | Value |
|---|---|
| No. | 1076385 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
