2022 Sany SY215C

1/9
Buy Sany SY215C Used Excavator / 1
Buy Sany SY215C Used Excavator / 2
Buy Sany SY215C Used Excavator / 3
Buy Sany SY215C Used Excavator / 4
Buy Sany SY215C Used Excavator / 5
Buy Sany SY215C Used Excavator / 6
Buy Sany SY215C Used Excavator / 7
Buy Sany SY215C Used Excavator / 8
Buy Sany SY215C Used Excavator / 9

Product Description

This 2022 Sany SY215C excavator from Sichuan, China represents reliable mid-size equipment from one of the industry's leading manufacturers. With minimal operating hours since its 2022 manufacture date, this 21-ton class machine combines proven hydraulic performance with fuel-efficient power delivery suitable for earthmoving, site preparation, and general construction applications.

Key specifications include:

  • Operating weight: approximately 21,500 kg
  • Engine power: rated around 115 kW
  • Bucket capacity: standard 0.92 m³
  • Maximum digging depth: approximately 6,700 mm
  • Hydraulic system with multi-mode operation

The SY215C platform offers straightforward serviceability and parts availability across global markets. This unit is currently located in Sichuan and available for inspection. Contact us for detailed specifications, service records, and export documentation assistance.

SpecificationsValue
No.1170452
Tonnage (tons)21
Working weight (kg)21900
Bucket capacity (m³)1.1 (0.8~1.2)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeMitsubishi 4M50
Rated power (kw/rpm)118/2000
Cooling modewater-cooling
Maximum torque (N.m)580/1600
Number of cylinders (PCS)4
Displacement (L)4.9
Ground specific pressure (Kpa)47.4
Rotation speed (rpm)11
Climbing ability (%)70% (35°)
Bucket digging force (kN)138
Rod digging force (kN)103
Travel speed (km/h)5.4/3.3
Fuel Tank (L)390
Hydraulic Tank (L)239
Engine Oil changes (L)22
Total transport length (mm)9680
Total transport width (mm)2980
Total transport height (mm)3440
Full cab height (mm)3075
Minimum ground clearance (mm)440
Minimum turning radius of front working device (mm)3730
Back end turning radius (mm)2900
Onboard width (mm)2875
Total track length (mm)4250
Track gauge (mm)2380
Track plate width (mm)600
Track ground length (mm)3445
Maximum height at minimum turning radius (mm)7680
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)8
Number of track plates (single side) (PCS)47
Maximum digging radius (mm)10280
Maximum digging depth (mm)6600
Maximum excavation height (mm)9600
Maximum unloading height (mm)6730
see more

Overview

No.1170452

Brand Name:

Sany

Model Number:

SY215C

Year:

2022

Location:

Sichuan China

Pub Date:
