2020 Sany SY215C-8

1/6
Buy Sany SY215C-8 Used Excavator / 1
Buy Sany SY215C-8 Used Excavator / 2
Buy Sany SY215C-8 Used Excavator / 3
Buy Sany SY215C-8 Used Excavator / 4
Buy Sany SY215C-8 Used Excavator / 5
Buy Sany SY215C-8 Used Excavator / 6

Product Description

Used 2020 Sany SY215C-8 excavator available from Sichuan, China. This 21.5-ton class crawler excavator comes equipped with a grapple attachment and is offered without bucket. The SY215C-8 features Sany's proven hydraulic system and reliable diesel engine, designed for earthmoving, demolition, and material handling applications.

This machine represents solid value in the mid-size excavator category. The grapple configuration makes it particularly suitable for scrap handling, forestry work, and demolition projects where material sorting is required.

  • Year: 2020
  • Model: Sany SY215C-8
  • Configuration: Grapple attachment, no bucket
  • Location: Sichuan Province, China
  • Condition: Used

Inspection reports and additional documentation available upon request. Suitable for export or domestic use.

SpecificationsValue
No.1163253
Tonnage (tons)21
Working weight (kg)20900
Bucket capacity (m³)0.93
Country of originKunshan in Jiangsu Province
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeMitsubishi 6D34-TL
Rated power (kw/rpm)114/2050
Cooling modewater-cooling
Ground specific pressure (Kpa)45
Rotation speed (rpm)12.5
Climbing ability (%)70/35 °
Bucket digging force (kN)138
Travel speed (km/h)3.2/5.5
Main overflow set pressure (Mpa)34.3
Maximum flow of main pump (l/min)2 x 210
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25.5
Control Hydraulic Circuit (Mpa)3.9
Hydraulic crushing pipeline is standardno
Total transport length (mm)9397
Total transport width (mm)2980
Total transport height (mm)2956
Full cab height (mm)2930
Minimum ground clearance (mm)440
Back end turning radius (mm)2750
Total track length (mm)4250
Track gauge (mm)2380
Track plate width (mm)600
Total track width (mm)2980
Track ground length (mm)3445
Maximum digging radius (mm)9885
Maximum digging depth (mm)6630
Maximum excavation height (mm)9305
Maximum unloading height (mm)6475
Maximum vertical digging depth (mm)5980
Bulldozer lift or depth (mm)There is no
see more

Overview

No.1163253

Brand Name:

Sany

Model Number:

SY215C-8

Year:

2020

Location:

Sichuan China

Pub Date:
