2020 Sany SY235C-8

1/4
Buy Sany SY235C-8 Used Excavator / 1
Buy Sany SY235C-8 Used Excavator / 2
Buy Sany SY235C-8 Used Excavator / 3
Buy Sany SY235C-8 Used Excavator / 4

Product Description

This 2020 Sany SY235C-8 hydraulic excavator offers reliable performance for demanding construction and earthmoving applications. With approximately 4 years of operational service, this mid-size crawler excavator combines proven Chinese engineering with practical field capabilities. The SY235C-8 series is known for its fuel-efficient engine, robust undercarriage, and operator-focused cab design.

Currently located in Zhejiang, China, this machine represents an economical solution for contractors seeking dependable excavation equipment. Key features include:

  • 23-ton operating weight class suitable for general construction
  • Hydraulic system designed for smooth operation and precise control
  • Reinforced boom and arm structure for extended durability
  • Standard auxiliary hydraulic circuit for attachment versatility

Ideal for site development, trenching, loading operations, and material handling. Available for immediate inspection and export coordination from Zhejiang province.

SpecificationsValue
No.1172222
Tonnage (tons)23
Working weight (kg)22900
Bucket capacity (m³)1
Country of originKunshan in Jiangsu Province
powerTraditional power
manufacturerMade in China
bucketbackhoe
Rated power (kw/rpm)125/2100
Cooling modewater-cooling
Ground specific pressure (Kpa)47.6
Rotation speed (rpm)11
Climbing ability (%)70/35 °
Bucket digging force (kN)159
Travel speed (km/h)3.2/5.5
Main overflow set pressure (Mpa)34.3
Maximum flow of main pump (l/min)2 x 265
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25.5
Control Hydraulic Circuit (Mpa)3.9
Hydraulic crushing pipeline is standardno
Total transport length (mm)9780
Total transport width (mm)2980
Total transport height (mm)3160
Full cab height (mm)2930
Minimum ground clearance (mm)440
Back end turning radius (mm)2860
Total track length (mm)4445
Track gauge (mm)2380
Track plate width (mm)600
Total track width (mm)2980
Track ground length (mm)3640
Maximum digging radius (mm)10180
Maximum digging depth (mm)6920
Maximum excavation height (mm)9380
Maximum unloading height (mm)6515
Maximum vertical digging depth (mm)6010
Bulldozer lift or depth (mm)There is no
see more

Overview

No.1172222

Brand Name:

Sany

Model Number:

SY235C-8

Year:

2020

Location:

Zhejiang China

Pub Date:
