Product Description
This 2017 Sany SY245H hydraulic excavator offers reliable performance for medium to heavy-duty earthmoving applications. Sourced from Fujian, China, this machine features original factory bodywork and genuine hour meter readings, ensuring transparency in its operational history. The unit comes with complete documentation and is available for immediate delivery.
- Year of Manufacture: 2017
- Model: Sany SY245H
- Operating Weight Class: Approximately 24-25 tonnes
- Condition: Used with original panels intact
- Documentation: Complete ownership papers included
- Location: Fujian Province, China
- Availability: In stock and ready for shipment
Ideal for construction contractors and earthmoving operations requiring proven mid-size excavator capacity. The SY245H is recognized for its balance of digging force, reach, and fuel efficiency in its weight category.
| Specifications | Value |
|---|---|
| No. | 1173589 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
