2020 Sany SY245H

1/6
Buy Sany SY245H Used Excavator / 1
Buy Sany SY245H Used Excavator / 2
Buy Sany SY245H Used Excavator / 3
Buy Sany SY245H Used Excavator / 4
Buy Sany SY245H Used Excavator / 5
Buy Sany SY245H Used Excavator / 6

Product Description

Well-maintained 2020 Sany SY245H hydraulic excavator available for sale from Fujian, China. This mid-size crawler excavator was purchased new in 2020 and has been consistently maintained throughout its operational life. The SY245H is recognized in the construction and earthmoving sectors for its reliable performance in general excavation, trenching, and material handling applications.

Key features include:

  • Operating weight approximately 24-25 tons
  • Hydraulic system designed for efficient cycle times
  • Cab with standard operator controls and visibility
  • Suitable for infrastructure, mining, and demolition projects
  • Currently located in Fujian Province, China

This machine represents a practical acquisition for contractors seeking proven equipment at an accessible price point. Serious inquiries are welcomed for detailed specifications, operating hours, and commercial terms.

SpecificationsValue
No.1156836
Tonnage (tons)24
Working weight (kg)25500
Bucket capacity (m³)1.3~1.5(1.5)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeD06FRC
Rated power (kw/rpm)147/2100
Cooling modewater-cooling
Maximum torque (N.m)750/1350
Number of cylinders (PCS)6
Displacement (L)6.373
Ground specific pressure (Kpa)53.2
Rotation speed (rpm)10.6
Climbing ability (%)70
Bucket digging force (kN)175
Rod digging force (kN)120
Travel speed (km/h)5.4/3.4
Fuel Tank (L)475
Hydraulic Tank (L)277
Engine Oil changes (L)29
Total transport length (mm)10290
Total transport width (mm)3190
Total transport height (mm)3190
Full cab height (mm)3255
Minimum ground clearance (mm)470
Minimum turning radius of front working device (mm)3800
Back end turning radius (mm)3105
Onboard width (mm)3045
Total track length (mm)4445
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)3640
Maximum height at minimum turning radius (mm)8016
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)49
Maximum digging radius (mm)10225
Maximum digging depth (mm)6705
Maximum excavation height (mm)9745
Maximum unloading height (mm)6715
see more

Overview

No.1156836

Brand Name:

Sany

Model Number:

SY245H

Year:

2020

Location:

Fujian China

Pub Date:
