Product Description
This 2020 Sany SY245H hydraulic excavator offers reliable performance for demanding excavation and earthmoving applications. Manufactured by Sany Heavy Industry, a leading Chinese construction equipment producer, this mid-size crawler excavator features robust build quality and operational efficiency suited for contractors and site development projects.
Currently located in Sichuan, China, this machine represents an accessible entry point into quality used heavy equipment. The SY245H series is engineered for productivity in various ground conditions, delivering consistent hydraulic power and cycle times essential for commercial operations.
- Year of Manufacture: 2020
- Model: Sany SY245H
- Equipment Type: Hydraulic Crawler Excavator
- Current Location: Sichuan Province, China
- Condition: Used
Suitable for construction, mining, and infrastructure development. Inspection available upon request. Contact FairTradeMachinery for detailed specifications, current operating hours, and export documentation assistance.
| Specifications | Value |
|---|---|
| No. | 1171500 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
