Product Description
Now available from FairTradeMachinery: a 2021 Sany SY245H hydraulic excavator, held in stock in Fujian, China. This is a one-owner machine offered directly by the current operator, who remains on site for inspection and handover. Detailed photographs and a full walkaround video are available before you commit to a visit.
The SY245H sits in the 24-tonne class and is a common choice for earthworks, road construction, trenching and general site excavation. As with any used unit, we recommend a physical inspection and verification of the hour meter, undercarriage, hydraulic system and service records against the machine itself.
- Year: 2021
- Brand: Sany
- Model: SY245H
- Location: Fujian, China
- Ownership: first-hand, owner present on site
- Documentation: detailed photos and video on request
- Availability: in stock now
- Price: in the RMB 200,000+ range
Export paperwork, loading and inland transport out of Fujian can be coordinated through our team. Contact us for the full media package, an inspection appointment and the current asking price.
| Specifications | Value |
|---|---|
| No. | 1156626 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
