2021 Sany SY26U

1/6
Buy Sany SY26U Used Excavator / 1
Buy Sany SY26U Used Excavator / 2
Buy Sany SY26U Used Excavator / 3
Buy Sany SY26U Used Excavator / 4
Buy Sany SY26U Used Excavator / 5
Buy Sany SY26U Used Excavator / 6

Product Description

This 2021 Sany SY26U mini excavator represents a reliable solution for compact construction and excavation projects. Manufactured by Sany Heavy Industry, a leading Chinese construction equipment producer, this unit comes from its original owner in Zhejiang Province, China.

The SY26U is designed for versatility in confined spaces, making it ideal for urban construction, landscaping, and utility work. As a mini excavator from Sany's proven lineup, it combines maneuverability with operational efficiency for demanding job sites.

Key features include:

  • Model year: 2021
  • Single previous owner
  • Compact footprint for tight access
  • Located in Zhejiang, China
  • Suitable for rental fleets and contractors

This unit offers an economical entry point into quality used construction equipment with the backing of Sany's engineering standards.

SpecificationsValue
No.1118193
Tonnage (tons)2
Working weight (kg)2680
Bucket capacity (m³)0.04-0.08(0.06)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeYanmar 3TNV80F
Rated power (kw/rpm)15.2/2500
Maximum torque (N.m)63.2-67.4/1800-100
Displacement (L)1.266
Ground specific pressure (Kpa)25.5
Rotation speed (rpm)10
Climbing ability (%)47
Bucket digging force (kN)24.3
Rod digging force (kN)14.2
Travel speed (km/h)4.5/2.6
Fuel Tank (L)34
Hydraulic Tank (L)30
Engine Oil changes (L)3.4/1.6
Total transport length (mm)4285
Total transport width (mm)1550
Total transport height (mm)2430
Minimum ground clearance (mm)290
Minimum turning radius of front working device (mm)2110
Back end turning radius (mm)775
Total track length (mm)2005
Track gauge (mm)1250
Track plate width (mm)300
Track ground length (mm)1560
Maximum height at minimum turning radius (mm)3200
Number of wheels (single side) (each)3
Maximum digging radius (mm)4850
Maximum digging depth (mm)2820
Maximum excavation height (mm)4410
Maximum unloading height (mm)3100
Maximum vertical digging depth (mm)2585
Bulldozer lift or depth (mm)360/330
Dodging plate width × height (mm)300 (height)
see more

Overview

No.1118193

Brand Name:

Sany

Model Number:

SY26U

Year:

2021

Location:

Zhejiang China

Pub Date
