2018 Sany SY305H

1/8
Buy Sany SY305H Used Excavator / 1
Buy Sany SY305H Used Excavator / 2
Buy Sany SY305H Used Excavator / 3
Buy Sany SY305H Used Excavator / 4
Buy Sany SY305H Used Excavator / 5
Buy Sany SY305H Used Excavator / 6
Buy Sany SY305H Used Excavator / 7
Buy Sany SY305H Used Excavator / 8

Product Description

This 2018 Sany SY305H hydraulic excavator offers reliable performance for medium to heavy-duty earthmoving applications. Manufactured by one of China's leading construction equipment brands, this unit features a robust design suitable for demanding job sites. The machine has been maintained in operational condition and is currently located in Fujian Province, China.

Key features of the SY305H model:

  • 30-ton operating class with strong digging force
  • Fuel-efficient engine designed for extended operation
  • Spacious operator cab with good visibility
  • Durable undercarriage and track system
  • Suitable for excavation, loading, and material handling tasks

This excavator represents a cost-effective solution for contractors seeking proven Sany performance. With limited operating hours indicated, the machine is positioned to deliver continued productivity. Contact us for detailed specifications, current condition assessment, and export assistance from China.

SpecificationsValue
No.1152598
Tonnage (tons)30
Working weight (kg)31500
Bucket capacity (m³)1.65~2.0(1.65)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeIsuzu GH-6HK1
Rated power (kw/rpm)212/2000
Cooling modewater-cooling
Maximum torque (N.m)1080/1500
Number of cylinders (PCS)6
Displacement (L)7.79
Ground specific pressure (Kpa)62.3
Rotation speed (rpm)9.0
Climbing ability (%)70% (35°)
Bucket digging force (kN)204
Rod digging force (kN)153
Travel speed (km/h)5.4/3.2
Fuel Tank (L)540
Hydraulic Tank (L)380
Engine Oil changes (L)2*4.0
Coolant (L)35
Total transport length (mm)10667
Total transport width (mm)3190
Total transport height (mm)3470
Full cab height (mm)3280
Minimum ground clearance (mm)550
Minimum turning radius of front working device (mm)4000
Back end turning radius (mm)3315
Onboard width (mm)3175
Total track length (mm)4840
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)3916
Maximum height at minimum turning radius (mm)8405
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)8
Number of track plates (single side) (PCS)47
Maximum digging radius (mm)10870
Maximum digging depth (mm)6815
Maximum excavation height (mm)10497
Maximum unloading height (mm)7359
Maximum vertical digging depth (mm)6170
see more

Overview

No.1152598

Brand Name:

Sany

Model Number:

SY305H

Year:

2018

Location:

Fujian China

Pub Date:

Are you interested in this machine?

Please contact us
