Product Description
This 2021 Sany SY35U compact excavator offers reliable performance with 3,200 operational hours. Located in Guangdong, China, this 3.5-ton class machine is ready for immediate deployment to your worksite. The unit has been maintained to operational standards and is field-ready.
Key features include:
- Compact design ideal for urban construction and confined spaces
- Zero tail swing configuration for enhanced maneuverability
- Low hour count relative to model year
- Suitable for excavation, trenching, and light demolition work
- Cost-effective solution for contractors and rental fleets
The SY35U is a proven workhorse in the mini excavator segment, combining Sany's engineering with practical jobsite capability. This unit represents an economical entry point for expanding your equipment fleet without compromising on build quality or operational readiness.
| Specifications | Value |
|---|---|
| No. | 1163767 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3780 |
| Bucket capacity (m³) | 0.06-0.15(0.12) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV88 Stages3A EPA int4 |
| Rated power (kw/rpm) | 20.4/2200 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 107/1300 |
| Displacement (L) | 1.642 |
| Ground specific pressure (Kpa) | 32 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 58 |
| Bucket digging force (kN) | 30.4 |
| Rod digging force (kN) | 18.2 |
| Travel speed (km/h) | 4.4/2.4 |
| Fuel Tank (L) | 40 |
| Hydraulic Tank (L) | 40 |
| Engine Oil changes (L) | 6 |
| Total transport length (mm) | 4915 |
| Total transport width (mm) | 1720 |
| Total transport height (mm) | 2515 |
| Minimum ground clearance (mm) | 295 |
| Back end turning radius (mm) | 860 |
| Total track length (mm) | 2155 |
| Track gauge (mm) | 1420 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1670 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 4 |
| Maximum digging radius (mm) | 5465 |
| Maximum digging depth (mm) | 3105 |
| Maximum excavation height (mm) | 4855 |
| Maximum unloading height (mm) | 3460 |
| Maximum vertical digging depth (mm) | 2700 |
| Bulldozer lift or depth (mm) | 375/370 |
