Product Description
Discover the 2021 Sany SY420C, a robust and reliable excavator available in Zhejiang, China. This machine is designed for heavy-duty applications, offering exceptional performance and durability. The SY420C is ideal for construction, mining, and large-scale earthmoving projects, providing high efficiency and low operating costs. Built with advanced technology and Sany's commitment to quality, this excavator ensures long-lasting productivity and minimal downtime.
- Year: 2021
- Brand: Sany
- Model: SY420C
- Location: Zhejiang, China
| Specifications | Value |
|---|---|
| No. | 1120029 |
| Tonnage (tons) | 42 |
| Working weight (kg) | 41600 |
| Bucket capacity (m³) | 2 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 6D24-TLU2G |
| Rated power (kw/rpm) | 235/2000 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 80 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 264.5 |
| Rod digging force (kN) | 229.4 |
| Travel speed (km/h) | 3.2-5.2 |
| Maximum flow of main pump (l/min) | 2 x 360 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 28.4 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 12070 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 4000 |
| Full cab height (mm) | 3230 |
| Minimum ground clearance (mm) | 570 |
| Back end turning radius (mm) | 3800 |
| Total track length (mm) | 5075 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3340 |
| Track ground length (mm) | 4020 |
| Maximum digging radius (mm) | 11625 |
| Maximum digging depth (mm) | 7375 |
| Maximum excavation height (mm) | 10740 |
| Maximum unloading height (mm) | 7380 |
| Maximum vertical digging depth (mm) | 5800 |
| Bulldozer lift or depth (mm) | There is no |
