HOME>>Sany>>Sany SY420C

2021 Sany SY420C

1/9
Buy Sany SY420C Used Excavator / 1
Buy Sany SY420C Used Excavator / 2
Buy Sany SY420C Used Excavator / 3
Buy Sany SY420C Used Excavator / 4
Buy Sany SY420C Used Excavator / 5
Buy Sany SY420C Used Excavator / 6
Buy Sany SY420C Used Excavator / 7
Buy Sany SY420C Used Excavator / 8
Buy Sany SY420C Used Excavator / 9

Product Description

Discover the 2021 Sany SY420C, a robust and reliable excavator designed for heavy-duty applications. Located in Zhejiang, China, this machine is an excellent choice for construction, mining, and large-scale earthmoving projects. Built with Sany’s renowned engineering, the SY420C offers superior performance, durability, and efficiency. Ideal for businesses seeking a powerful and versatile solution, this excavator is ready to meet the demands of your next project.

  • Year: 2021
  • Brand: Sany
  • Model: SY420C
  • Location: Zhejiang, China
SpecificationsValue
No.1120185
Tonnage (tons)42
Working weight (kg)41600
Bucket capacity (m³)2
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine type6D24-TLU2G
Rated power (kw/rpm)235/2000
Cooling modewater-cooling
Ground specific pressure (Kpa)80
Rotation speed (rpm)9.3
Climbing ability (%)70% / 35 °
Bucket digging force (kN)264.5
Rod digging force (kN)229.4
Travel speed (km/h)3.2-5.2
Maximum flow of main pump (l/min)2 x 360
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)28.4
Control Hydraulic Circuit (Mpa)3.9
Hydraulic crushing pipeline is standardno
Total transport length (mm)12070
Total transport width (mm)3340
Total transport height (mm)4000
Full cab height (mm)3230
Minimum ground clearance (mm)570
Back end turning radius (mm)3800
Total track length (mm)5075
Track gauge (mm)2740
Track plate width (mm)600
Total track width (mm)3340
Track ground length (mm)4020
Maximum digging radius (mm)11625
Maximum digging depth (mm)7375
Maximum excavation height (mm)10740
Maximum unloading height (mm)7380
Maximum vertical digging depth (mm)5800
Bulldozer lift or depth (mm)There is no
see more

Overview

No.1120185

Brand Name:

Sany

Model Number:

SY420C

Year:

2021

Location:

Zhejiang China

Pub Date
