Product Description
Proven performance meets exceptional value in this 2020 Sany SY55C mini excavator, currently located in Nanning, Guangxi. Powered by a reliable 4JG1 engine delivering 36kW at 2100rpm, this 5.78-ton machine offers the productivity of new equipment at a fraction of the cost. With a maximum digging depth of 3,815mm and digging radius of 6,090mm, it handles demanding excavation tasks efficiently while maintaining a compact footprint ideal for urban jobsites and confined spaces.
- Engine: 4JG1, 36kW/2100rpm, water-cooled
- Operating Weight: 5,780kg
- Bucket Capacity: 0.21m³ (range: 0.1-0.28m³)
- Digging Force: 45kN (bucket), 33kN (arm)
- Max Digging Depth: 3,815mm
- Max Digging Radius: 6,090mm
- Fuel Capacity: 130L
- Climbing Ability: 70% (35°)
Investing in quality pre-owned machinery delivers immediate ROI without the depreciation hit of purchasing new. This Chinese-manufactured excavator combines robust construction with lower acquisition costs, making it a smart choice for contractors seeking reliable performance on budget.
| Specifications | Value |
|---|---|
| No. | 1022465 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5780 |
| Bucket capacity (m³) | 0.1~0.28(0.21) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4JG1 |
| Rated power (kw/rpm) | 36/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 175/1800 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Ground specific pressure (Kpa) | 32.75 |
| Rotation speed (rpm) | 9.6 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 45 |
| Rod digging force (kN) | 33 |
| Travel speed (km/h) | 3.73/2.4 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 9.6 |
| Total transport length (mm) | 5925 |
| Total transport width (mm) | 2005 |
| Total transport height (mm) | 2595 |
| Minimum ground clearance (mm) | 330 |
| Back end turning radius (mm) | 1640 |
| Total track length (mm) | 2545 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 5 |
| Number of track plates (single side) (PCS) | 40 |
| Maximum digging radius (mm) | 6090 |
| Maximum digging depth (mm) | 3815 |
| Maximum excavation height (mm) | 5690 |
| Maximum unloading height (mm) | 3930 |
| Maximum vertical digging depth (mm) | 3070 |
| Bulldozer lift or depth (mm) | 385/380 |
