2020 Sany SY55C-9

1/9
Buy Sany SY55C-9 Used Excavator / 1
Buy Sany SY55C-9 Used Excavator / 2
Buy Sany SY55C-9 Used Excavator / 3
Buy Sany SY55C-9 Used Excavator / 4
Buy Sany SY55C-9 Used Excavator / 5
Buy Sany SY55C-9 Used Excavator / 6
Buy Sany SY55C-9 Used Excavator / 7
Buy Sany SY55C-9 Used Excavator / 8
Buy Sany SY55C-9 Used Excavator / 9

Product Description

This 2020 Sany SY55C-9 mini excavator is available for immediate sale from Anhui, China. As part of Sany's reliable 5-ton class excavator lineup, the SY55C-9 offers excellent maneuverability and performance for various construction and earthmoving applications. With approximately 3-4 years of operational use, this machine represents a cost-effective solution for contractors seeking dependable equipment.

  • Year of Manufacture: 2020
  • Make and Model: Sany SY55C-9
  • Operating Weight Class: 5.5 tons
  • Current Location: Anhui Province, China
  • Status: Used, available for sale
  • Seller Note: Ready for offers and immediate transaction

The SY55C-9 is known for its compact design, fuel efficiency, and ease of transport, making it ideal for urban construction sites, utility work, and landscaping projects. Interested buyers are encouraged to contact us directly for pricing, additional specifications, and shipping arrangements to your location.

SpecificationsValue
No.1120519
Tonnage (tons)5
Working weight (kg)5780
Bucket capacity (m³)0.21 (optional 0.23)
Country of originChina
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeIsuzu 4JG1-NABGB-04-C2
Rated power (kw/rpm)40.9/2100
Cooling modewater-cooling
Maximum torque (N.m)191/1800
Number of cylinders (PCS)4-cylinder
Displacement (L)3.059
Working form4 cylinder, 4 stroke, water cooled, direct injection
Ground specific pressure (Kpa)32.75
Rotation speed (rpm)9.6
Climbing ability (%)70% / 35 °
Bucket digging force (kN)45
Rod digging force (kN)33
Travel speed (km/h)3.73/2.40
Fuel Tank (L)130
Hydraulic Tank (L)85
Engine Oil changes (L)9.63
Total transport length (mm)5925
Total transport width (mm)2005
Total transport height (mm)2595
Minimum ground clearance (mm)330
Minimum turning radius of front working device (mm)2555
Back end turning radius (mm)1640
Onboard width (mm)1860
Total track length (mm)2545
Track gauge (mm)1600
Track plate width (mm)400
Total track width (mm)2000
Maximum digging radius (mm)6090
Maximum digging depth (mm)3815
Maximum excavation height (mm)5690
Maximum unloading height (mm)3930
Maximum vertical digging depth (mm)3070
Bulldozer lift or depth (mm)Lift 435 and push 420
Dodging plate width × height (mm)Height 340
