HOME>>Sany>>Sany SY70C

2024 Sany SY70C

1/5
Buy Sany SY70C Used Excavator / 1
Buy Sany SY70C Used Excavator / 2
Buy Sany SY70C Used Excavator / 3
Buy Sany SY70C Used Excavator / 4
Buy Sany SY70C Used Excavator / 5

Product Description

Built to outlast demanding job sites, the Sany SY70C is a 7-ton compact excavator that proves its worth through performance, not promises. Manufactured in China and sourced directly from Sichuan, this 2024 machine carries a 45.4 kW Kubota V2607 water-cooled diesel engine rated at 2,400 rpm — delivering 217 N·m of torque and a bucket digging force of 51 kN. It is a proven workhorse engineered for precision and endurance in equal measure.

  • Working Weight: 6,800 kg | 7-ton class
  • Bucket Capacity: 0.12–0.32 m³ (standard 0.28 m³ backhoe)
  • Maximum Digging Depth: 4,065 mm effective | 3,335 mm vertical
  • Maximum Excavation Height: 7,010 mm
  • Bucket / Rod Digging Force: 51 kN / 36 kN
  • Travel Speed: 4.2 / 2.4 km/h | Climbing Ability: 70%
  • Ground Pressure: 33 kPa | Track Width: 400 mm
  • Fuel Tank: 150 L | Hydraulic Tank: 120 L
  • Transport Dimensions: 6,120 × 2,140 × 2,645 mm

Compact enough for confined sites yet capable across rough terrain, the SY70C is ready to work from day one. Stock held in Sichuan, China — available for immediate inspection and export.

SpecificationsValue
No.1142127
Tonnage (tons)7
Working weight (kg)6800
Bucket capacity (m³)0.12~0.32 (0.28)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeV2607-DI-T-ET06e
Rated power (kw/rpm)45.4/2400
Cooling modewater-cooling
Maximum torque (N.m)217/1600
Displacement (L)2.615
Ground specific pressure (Kpa)33
Rotation speed (rpm)11.5
Climbing ability (%)70
Bucket digging force (kN)51
Rod digging force (kN)36
Travel speed (km/h)4.2/2.4
Fuel Tank (L)150
Hydraulic Tank (L)120
Engine Oil changes (L)10
Total transport length (mm)6120
Total transport width (mm)2140
Total transport height (mm)2645
Track plate width (mm)400
Number of sprockets (single side) (each)1
Number of wheels (single side) (each)5
Number of track plates (single side) (PCS)42
Maximum excavation height (mm)7010
Maximum unloading height (mm)5110
Maximum vertical digging depth (mm)3335
Maximum effective digging depth (mm)4065
see more

Overview

No.1142127

Brand Name:

Sany

Model Number:

SY70C

Year:

2024

Location:

Sichuan China

Pub Date
