2021 Sany SY750H

1/8
Buy Sany SY750H Used Excavator / 1
Buy Sany SY750H Used Excavator / 2
Buy Sany SY750H Used Excavator / 3
Buy Sany SY750H Used Excavator / 4
Buy Sany SY750H Used Excavator / 5
Buy Sany SY750H Used Excavator / 6
Buy Sany SY750H Used Excavator / 7
Buy Sany SY750H Used Excavator / 8

Product Description

Built for large-scale earthmoving and mining operations, the 2021 Sany SY750H is a 75-ton hydraulic excavator that delivers serious digging performance backed by one of the most reliable supply chains in the heavy equipment industry. Sany's global manufacturing scale means parts availability is rarely an issue — a critical advantage when downtime costs money.

With a bucket digging force of 402 kN, a maximum digging depth of 7,620 mm, and a bucket capacity ranging from 4.6 to 5.6 m³, this machine handles high-volume material movement with consistent output. Rated power sits at 377 kW at 1,800 rpm, and a climbing ability of 70% makes it capable across demanding terrain.

  • Working weight: 76,200 kg
  • Bucket digging force: 402 kN
  • Maximum digging depth: 7,620 mm
  • Maximum digging radius: 12,050 mm
  • Rated power: 377 kW / 1,800 rpm
  • Bucket capacity: 4.6–5.6 m³
  • Travel speed: 4.5 / 2.9 km/h

Sany holds strong resale value in the used market due to widespread dealer networks and consistent parts support across Asia, the Middle East, and Africa. Currently located in Zhejiang, China, this unit is well-positioned for export. A practical, high-capacity choice for buyers who need proven performance without the premium of European iron.

SpecificationsValue
No.1060669
Tonnage (tons)75
Working weight (kg)76200
Bucket capacity (m³)4.6-5.6
powerTraditional power
manufacturerMade in China
bucketbackhoe
Rated power (kw/rpm)377/1800
Ground specific pressure (Kpa)110
Rotation speed (rpm)7.3
Climbing ability (%)70
Bucket digging force (kN)402
Rod digging force (kN)345
Travel speed (km/h)4.5/2.9
Total transport length (mm)12865
Total transport width (mm)4320
Total transport height (mm)4855
Full cab height (mm)3800
Minimum ground clearance (mm)880
Minimum turning radius of front working device (mm)5520
Back end turning radius (mm)4220
Onboard width (mm)3460
Total track length (mm)5865
Track gauge (mm)3380/2780
Track plate width (mm)650
Track ground length (mm)4650
Maximum height at minimum turning radius (mm)9780
Maximum digging radius (mm)12050
Maximum digging depth (mm)7620
Maximum excavation height (mm)11200
Maximum unloading height (mm)7250
Maximum vertical digging depth (mm)4320
see more

Overview

No.1060669

Brand Name:

Sany

Model Number:

SY750H

Year:

2021

Location:

Zhejiang China
