Product Description
Built for large-scale earthmoving and mining operations, the 2021 Sany SY750H is a 75-ton hydraulic excavator that delivers serious digging performance backed by one of the most reliable supply chains in the heavy equipment industry. Sany's global manufacturing scale means parts availability is rarely an issue — a critical advantage when downtime costs money.
With a bucket digging force of 402 kN, a maximum digging depth of 7,620 mm, and a bucket capacity ranging from 4.6 to 5.6 m³, this machine handles high-volume material movement with consistent output. Rated power sits at 377 kW at 1,800 rpm, and a climbing ability of 70% makes it capable across demanding terrain.
- Working weight: 76,200 kg
- Bucket digging force: 402 kN
- Maximum digging depth: 7,620 mm
- Maximum digging radius: 12,050 mm
- Rated power: 377 kW / 1,800 rpm
- Bucket capacity: 4.6–5.6 m³
- Travel speed: 4.5 / 2.9 km/h
Sany holds strong resale value in the used market due to widespread dealer networks and consistent parts support across Asia, the Middle East, and Africa. Currently located in Zhejiang, China, this unit is well-positioned for export. A practical, high-capacity choice for buyers who need proven performance without the premium of European iron.
| Specifications | Value |
|---|---|
| No. | 1060669 |
| Tonnage (tons) | 75 |
| Working weight (kg) | 76200 |
| Bucket capacity (m³) | 4.6-5.6 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 377/1800 |
| Ground specific pressure (Kpa) | 110 |
| Rotation speed (rpm) | 7.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 402 |
| Rod digging force (kN) | 345 |
| Travel speed (km/h) | 4.5/2.9 |
| Total transport length (mm) | 12865 |
| Total transport width (mm) | 4320 |
| Total transport height (mm) | 4855 |
| Full cab height (mm) | 3800 |
| Minimum ground clearance (mm) | 880 |
| Minimum turning radius of front working device (mm) | 5520 |
| Back end turning radius (mm) | 4220 |
| Onboard width (mm) | 3460 |
| Total track length (mm) | 5865 |
| Track gauge (mm) | 3380/2780 |
| Track plate width (mm) | 650 |
| Track ground length (mm) | 4650 |
| Maximum height at minimum turning radius (mm) | 9780 |
| Maximum digging radius (mm) | 12050 |
| Maximum digging depth (mm) | 7620 |
| Maximum excavation height (mm) | 11200 |
| Maximum unloading height (mm) | 7250 |
| Maximum vertical digging depth (mm) | 4320 |
