Product Description
With a robust 7-ton working weight and a powerful Isuzu CC-4JG1PAC engine, this 2018 Sany SY75C-8 excavator offers reliable performance. Made in China, Sany is renowned for its durable construction and global parts availability, ensuring minimal downtime and cost-effective maintenance. The machine boasts a 0.28 m³ bucket capacity and a maximum digging depth of 4060 mm, making it ideal for various excavation tasks. Its 2.6-4.2 km/h travel speed and 70% climbing ability enhance maneuverability on challenging terrains.
- Rated power: 40 kW at 2100 rpm
- Bucket digging force: 49 kN
- Ground specific pressure: 28 Kpa
- Maximum flow of main pump: 149 l/min
- Total transport dimensions: 6000 mm (length) x 2220 mm (width) x 2620 mm (height)
Choose the Sany SY75C-8 for its strong resale value and dependable performance, backed by a trusted brand in the used heavy equipment market.
| Specifications | Value |
|---|---|
| No. | 1021228 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 6800 |
| Bucket capacity (m³) | 0.28 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu CC-4JG1PAC |
| Rated power (kw/rpm) | 40/2100 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 28 |
| Rotation speed (rpm) | 10.9 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 49 |
| Rod digging force (kN) | 35 |
| Travel speed (km/h) | 2.6-4.2 |
| Maximum flow of main pump (l/min) | 149 |
| Traveling Hydraulic Circuit (Mpa) | 26 |
| Rotary Hydraulic Circuit (Mpa) | 21.6 |
| Control Hydraulic Circuit (Mpa) | 3.6 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2620 |
| Full cab height (mm) | 2620 |
| Minimum ground clearance (mm) | 355 |
| Back end turning radius (mm) | 1720 |
| Total track length (mm) | 2710 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2220 |
| Track ground length (mm) | 2170 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 4060 |
| Maximum excavation height (mm) | 7070 |
| Maximum unloading height (mm) | 5110 |
| Maximum vertical digging depth (mm) | 3410 |
| Bulldozer lift or depth (mm) | 390 |
