Product Description
This 2020 Sany SY75C-8 mini excavator offers reliable performance for construction, landscaping, and utility projects. With approximately 7.5-ton operating weight and compact dimensions, this machine delivers excellent maneuverability in confined job sites while maintaining robust digging capabilities.
Currently located in Sichuan, China, this unit represents solid value in the used equipment market. The SY75C-8 features Sany's proven hydraulic system, fuel-efficient engine, and operator-focused cabin design for extended work cycles.
- Year: 2020
- Model: Sany SY75C-8
- Category: Mini Excavator
- Location: Sichuan, China
Ideal for contractors seeking dependable earthmoving equipment at competitive pricing. This excavator is available for inspection and ready for deployment to your next project site.
| Specifications | Value |
|---|---|
| No. | 1163901 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 6800 |
| Bucket capacity (m³) | 0.28 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu CC-4JG1PAC |
| Rated power (kw/rpm) | 40/2100 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 28 |
| Rotation speed (rpm) | 10.9 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 49 |
| Rod digging force (kN) | 35 |
| Travel speed (km/h) | 2.6-4.2 |
| Maximum flow of main pump (l/min) | 149 |
| Traveling Hydraulic Circuit (Mpa) | 26 |
| Rotary Hydraulic Circuit (Mpa) | 21.6 |
| Control Hydraulic Circuit (Mpa) | 3.6 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2620 |
| Full cab height (mm) | 2620 |
| Minimum ground clearance (mm) | 355 |
| Back end turning radius (mm) | 1720 |
| Total track length (mm) | 2710 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2220 |
| Track ground length (mm) | 2170 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 4060 |
| Maximum excavation height (mm) | 7070 |
| Maximum unloading height (mm) | 5110 |
| Maximum vertical digging depth (mm) | 3410 |
| Bulldozer lift or depth (mm) | 390 |
