Product Description
2011 Sany SY95C midi excavator equipped with extended arm configuration, based in Zhejiang, China. This 9.5-ton class machine offers enhanced reach for drainage, slope work, and foundation projects where standard boom length proves limiting. The extended arm modification provides additional versatility for contractors working in municipal infrastructure and site development applications.
With over 60,000 hours of documented operation, this unit represents a high-utilization asset from Sany's established C-series platform. The SY95C delivers reliable hydraulic performance in the compact excavator segment, suitable for buyers seeking proven equipment at competitive pricing.
- Year of Manufacture: 2011
- Model: Sany SY95C with extended boom
- Operating Hours: 60,000+
- Current Location: Zhejiang Province, China
- Configuration: Modified extended reach arm
Ideal for cost-conscious operations requiring extended digging radius. Inspection recommended prior to purchase.
| Specifications | Value |
|---|---|
| No. | 1141954 |
| Tonnage (tons) | 9 |
| Working weight (kg) | 9180 |
| Bucket capacity (m³) | 0.2-0.45 (0.39) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Kubota V3800DI-T-E3B |
| Rated power (kw/rpm) | 60.7/2200 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 305.4/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.769 |
| Ground specific pressure (Kpa) | 38.6 |
| Rotation speed (rpm) | 11.2 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 63.6 |
| Rod digging force (kN) | 46.8 |
| Travel speed (km/h) | 5.0/2.9 |
| Fuel Tank (L) | 160 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6560 |
| Total transport width (mm) | 2260 |
| Total transport height (mm) | 2650 |
| Minimum ground clearance (mm) | 360 |
| Minimum turning radius of front working device (mm) | 1990 |
| Back end turning radius (mm) | 1885 |
| Onboard width (mm) | 2160 |
| Total track length (mm) | 2980 |
| Track gauge (mm) | 1810 |
| Track plate width (mm) | 450 |
| Maximum height at minimum turning radius (mm) | 5700 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 5 |
| Number of track plates (single side) (PCS) | 41 |
| Maximum digging radius (mm) | 6660 |
| Maximum digging depth (mm) | 4330 |
| Maximum excavation height (mm) | 7260 |
| Maximum unloading height (mm) | 5210 |
| Maximum vertical digging depth (mm) | 3080 |
| Bulldozer lift or depth (mm) | 330/330 |
| Dodging plate width × height (mm) | 420 (height) |
