Product Description
Built for precision and control, this 2016 Sany SY95C-9 mini excavator delivers reliable performance across demanding jobsites. Powered by an Isuzu 4GJ1-TABA-01-C2 engine generating 53.8 kW at 2150 rpm, it combines responsive hydraulics with exceptional maneuverability in confined spaces. Operators benefit from stable ground-specific pressure of just 36 kPa and a compact 1990 mm rear swing radius, enabling confident work in urban environments and tight excavation zones.
- Operating weight: 8,850 kg with 0.39 m³ bucket capacity
- Superior digging force: 63.6 kN bucket, 46.8 kN stick
- Impressive reach: 6,660 mm maximum digging radius, 4,330 mm depth
- Smooth rotation: 11.2 rpm swing speed for efficient material handling
- Robust climbing ability: 70% grade capability (35°)
- Extended runtime: 160 L fuel tank, 130 L hydraulic reservoir
- Enhanced visibility: Full cab height 2,720 mm with 360 mm ground clearance
Currently located in Shaoxing, Zhejiang, this water-cooled machine offers proven durability for construction, landscaping, and utility projects requiring stable handling and precise control.
| Specifications | Value |
|---|---|
| No. | 1018764 |
| Tonnage (tons) | 9 |
| Working weight (kg) | 8850 |
| Bucket capacity (m³) | 0.39 |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu 4GJ1-TABA-01-C2 |
| Rated power (kw/rpm) | 53.8/2150 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 255/1800 |
| Displacement (L) | 3.059 |
| Working form | 4 cylinder, 4 stroke, water cooled, direct injection |
| Ground specific pressure (Kpa) | 36 |
| Rotation speed (rpm) | 11.2 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 63.6 |
| Rod digging force (kN) | 46.8 |
| Travel speed (km/h) | 5.0/2.9 |
| Fuel Tank (L) | 160 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 9 |
| Total transport length (mm) | 6560 |
| Total transport width (mm) | 2260 |
| Total transport height (mm) | 2720 |
| Full cab height (mm) | 2720 |
| Minimum ground clearance (mm) | 360 |
| Back end turning radius (mm) | 1990 |
| Onboard width (mm) | 2160 |
| Total track length (mm) | 2980 |
| Track gauge (mm) | 1810 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2340 |
| Maximum digging radius (mm) | 6660 |
| Maximum digging depth (mm) | 4330 |
| Maximum excavation height (mm) | 7260 |
| Maximum unloading height (mm) | 5210 |
| Maximum vertical digging depth (mm) | 3080 |
| Bulldozer lift or depth (mm) | Lift 330/ push 330 |
| Dodging plate width × height (mm) | 420(height) |
