Product Description
This 2017 Sumitomo SH240-6 hydraulic excavator offers proven performance with 7,000 operating hours. Originally deployed for earthmoving applications, this machine demonstrates the reliability Sumitomo is known for in the construction equipment sector. Currently located in Shaanxi Province, China, this unit is available for export or domestic sale.
Key features of this excavator include:
- Low to moderate hours for a 2017 model year unit
- Dedicated earthmoving service history
- Sumitomo hydraulic technology and fuel efficiency
- Suitable for construction, excavation, and material handling operations
- Available for inspection in Xi'an area
This SH240-6 represents an opportunity to acquire quality Japanese-engineered equipment at used machine value. Contact us for additional specifications, current condition assessment, and international shipping arrangements.
| Specifications | Value |
|---|---|
| No. | 1168395 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 24800 |
| Bucket capacity (m³) | 1.2 |
| Boom length (mm) | 5850 |
| Rod length (mm) | 3000 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 132.1/2000 |
| Displacement (L) | 5.193 |
| Ground specific pressure (Kpa) | 54 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 162 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.5/3.5 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3/36.8 |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 147 |
| Hydraulic System (L) | 250 |
| Total transport length (mm) | 9930 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1100 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3950 |
| Back end turning radius (mm) | 2950 |
| Total track length (mm) | 4240 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6900 |
| Maximum excavation height (mm) | 9760 |
| Maximum unloading height (mm) | 6760 |
| Maximum vertical digging depth (mm) | 6140 |
