Product Description
Engineered for precision and reliability, this 2016 Sumitomo SH210-5 delivers exceptional performance in demanding excavation environments. Operating at 21 tons with a robust 117.3 kW engine, this hydraulic excavator combines power with operator-centered design for maximum productivity on any jobsite.
Operators benefit from superior visibility and ergonomic controls that reduce fatigue during extended shifts. The spacious cabin provides commanding sightlines across the 9.9-meter digging radius, while intuitive hydraulic controls ensure responsive handling. Stability is reinforced by a 2,800mm track gauge and optimized ground pressure of just 45 kPa, enabling confident operation on varied terrain.
- 142 kN bucket digging force handles tough materials efficiently
- Variable axial piston motor delivers smooth, controlled travel at dual speeds (3.4/5.6 km/h)
- 0.9-1.0 m³ bucket capacity maximizes cycle productivity
- 5,700mm boom and 2,900mm arm provide versatile reach and depth capabilities
- 410L fuel tank supports longer operating intervals
- Currently located in Kunming, Yunnan, ready for inspection
| Specifications | Value |
|---|---|
| No. | 1027709 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20600 |
| Bucket capacity (m³) | 0.9-1.0 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 117.3/1800 |
| Cylinder diameter × stroke (mm) | 115 x 125 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.193 |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 142 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 3.4/5.6 |
| Type of walking hydraulic motor | Variable axial piston motor |
| Maximum flow of main pump (l/min) | 422 |
| Main pump type | |
| Bucket cylinders - Number × diameter × stroke (mm) | |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 140 x 1460 |
| Boom cylinders - Number × diameter × stroke (mm) | |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 147 |
| Engine Oil changes (L) | 23.1 |
| Coolant (L) | 26 |
| Hydraulic System (L) | 240 |
| Total transport length (mm) | 9400 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2970 |
| Counterweight ground clearance (mm) | 1040 |
| Minimum ground clearance (mm) | 460 |
| Minimum turning radius of front working device (mm) | 3600 |
| Back end turning radius (mm) | 2720 |
| Total track length (mm) | 4180 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3370 |
| Maximum digging radius (mm) | 9900 |
| Maximum digging depth (mm) | 6650 |
| Maximum excavation height (mm) | 9610 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5960 |
