2018 Sumitomo SH210-6

1/5
Buy Sumitomo SH210-6 Used Excavator / 1
Buy Sumitomo SH210-6 Used Excavator / 2
Buy Sumitomo SH210-6 Used Excavator / 3
Buy Sumitomo SH210-6 Used Excavator / 4
Buy Sumitomo SH210-6 Used Excavator / 5

Product Description

Built for precision and power, this 2018 Sumitomo SH210-6 excavator delivers 117.3kW of reliable performance across demanding jobsites. Operating at 21 tons with a proven joint venture build quality, this machine handles earthmoving, foundation work, and demolition with consistent hydraulic force—142kN bucket digging power and 103kN arm force ensure productive cycles in hard-packed soil and fractured rock.

  • 0.85–1.0 m³ bucket capacity tackles high-volume excavation and precise grading
  • 9.9m maximum digging reach accesses trenches, slopes, and load zones efficiently
  • 5700mm boom and 2900mm arm configuration optimizes depth and dump height
  • 34.3 MPa hydraulic system maintains speed under load during extended shifts
  • 440mm ground clearance and 2800mm transport width enable quick site-to-site mobilization

Currently located in Wenzhou, Zhejiang, this SH210-6 arrives job-ready with 410L fuel capacity for full-day operation. Variable piston hydraulics and 11.5 rpm swing speed reduce cycle times on repetitive tasks. Ideal for contractors requiring proven 21-ton class performance without downtime.

SpecificationsValue
No.1042895
Tonnage (tons)21
Working weight (kg)21000
Bucket capacity (m³)0.85~1.0
Boom length (mm)5700
Rod length (mm)2900 / 2400
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine type
Rated power (kw/rpm)117.3/1800
Displacement (L)5.193
Ground specific pressure (Kpa)47 / 36
Rotation speed (rpm)11.5
Climbing ability (%)70
Bucket digging force (kN)142 / 152
Rod digging force (kN)103 / 110
Travel speed (km/h)5.6 / 3.4
Rotary hydraulic motor type
Type of walking hydraulic motorVariable capacity piston pump
Main pump type
Working Hydraulic Circuit (Mpa)34.3 / 36.8
Fuel Tank (L)410
Hydraulic Tank (L)147
Hydraulic System (L)240
Total transport length (mm)9400
Total transport width (mm)2800
Total transport height (mm)2970
Counterweight ground clearance (mm)1040
Minimum ground clearance (mm)440
Minimum turning radius of front working device (mm)3600
Back end turning radius (mm)2750
Total track length (mm)4180
Track plate width (mm)600
Total track width (mm)2800
Track ground length (mm)3370
Maximum digging radius (mm)9900/9420
Maximum digging depth (mm)6650/6110
Maximum excavation height (mm)9610/9410
Maximum unloading height (mm)6810/6590
Maximum vertical digging depth (mm)5960/5500
